2000KG FULLY POWERED PALLET TRUCK - LTLEPT20S RANGE
2000 kg Fully Powered Pallet Truck – LTLEPT20S Range
The LTLEPT20S is a fully electric pallet truck offering both powered drive and lift functions. Built for efficient material handling in warehouses, logistics operations, and manufacturing sites, this robust unit combines strength, speed, and smart technology. Available with 550 x 1000 mm or 550 x 1150 mm forks, and with an optional extra battery, it delivers extended uptime and total operational flexibility.
Technical Specifications
| Model | Capacity | Fork Sizes (W × L) | Load Centre | Overall Length | Lowered Fork Height | Max Fork Height | Travel Speed (L/U) | Gradeability (L/U) | Drive Motor | Lift Motor | Battery |
| LTLEPT20S | 2000 kg | 550 × 1000 mm or 550 × 1150 mm | 600 mm | 1402–1622 mm (depending on fork length) | 82 mm | 197 mm | 4 km/h / 5 km/h | 6% / 20% | 1.0 kW Brushless DC | 0.8 kW DC | 48 V / 15 Ah Lithium-ion (extra battery optional) |
Key Features
- Fully electric operation: Powered drive and lift functions for maximum efficiency and reduced strain on the operator.
- Dual fork sizes available: Choose from 550 x 1000 mm or 550 x 1150 mm to suit your application.
- Lithium-ion battery system: Fast charging, long-life 48V battery with option to add a second swappable battery for extended shifts.
- Compact and ergonomic: Designed for tight warehouse spaces, with smooth movement and intuitive controls.
- Safety built-in: Includes emergency stop button, anti-roll back protection, and robust polyurethane wheels.
- Low maintenance: Brushless drive motor and simple electrical system reduce service needs.
Typical Applications
- Warehouse pallet transport and order picking
- Production line material movement
- Retail distribution centres
- Industrial loading and unloading tasks
Related Products
Looking for a lighter capacity? See our 1500kg fully electric model. Need built-in weighing? View our ERGO1100 semi-electric scale truck.
Order Now
Call 0800 458 8025 or info@liftruck.co.uk to order your LTLEPT20S, request lead time details, or ask about fleet pricing. Optional second battery and accessories available on request.
Frequently Asked Questions
Product Specifications
1. What is the load capacity of the Lithium-Ion Powered Pallet Truck?
The Lithium-Ion Powered Pallet Truck supports up to 1,500 kg, making it suitable for handling both Euro and standard GKN/Chep pallets.
2. What are the fork dimensions of this pallet truck?
The pallet truck features fixed forks measuring 1,150 mm in length and 560 mm in width.
3. What type of battery is used in this pallet truck?
It uses a quick-change, maintenance-free 24V/20Ah lithium-ion battery, providing long operational times and increased productivity.
4. What safety features does the Lithium-Ion Powered Pallet Truck have?
The pallet truck includes an emergency push button, belly button, and electrobrake for enhanced safety during operation.
Usage and Operation
5. How does the lithium-ion battery benefit the pallet truck?
The lithium-ion battery allows for quick replacement, offers longer operational time, and boosts productivity by reducing downtime.
6. Is this pallet truck suitable for use in confined spaces?
Yes, the compact and lightweight design makes it highly maneuverable, even in tight spaces such as elevators and narrow aisles.
7. How does the ergonomic handle benefit the operator?
The ergonomic handle incorporates electric lifting functions, significantly reducing operator strain and enhancing comfort during use.
Maintenance and Care
8. What regular maintenance is required?
Regular maintenance includes checking the battery, hydraulic systems, and inspecting the wheels for wear and tear.
9. What is the warranty period for this product?
The Lithium-Ion Powered Pallet Truck comes with a standard warranty.
10. Are replacement parts available?
Yes, replacement parts such as the lithium-ion battery, wheels, and hydraulic components are available through our store.
Purchasing and Delivery
11. Do you offer bulk discounts for multiple units?
Yes, we offer competitive pricing for bulk orders. Please contact our sales team for a personalised quote.
12. How long does delivery take?
Standard delivery times are 2–3 business days.
13. Can I return the pallet truck if it doesn’t meet my needs?
Yes, we have a 30-day return policy. The product must be in its original condition and packaging.
Safety and Regulations
14. Is the Lithium-Ion Powered Pallet Truck compliant with safety standards?
Yes, it meets all relevant UK and EU safety regulations.
15. Are safety guidelines included with the product?
Yes, a user manual with safety and operational guidelines is included in the packaging.
